Литиевые батареи Lithium NG Victron Energy арт. BAT512110620

Назва характеристики

Величина

alarmFeature

Pre-alarm contact on BMS

automotive

ECE R10-6

batteryCapacityNominal

100 Ah

batteryTerminals

M8 threaded inserts

batteryVoltageNominal

12.8 V

batteryVoltageNominalBucket

12

bluetooth

In the BMS

bms

Lynx Smart BMS NG 500A / 1000A (M10 busbars), must be purchased separately

bmsCable

50 cm male and female cable with M8 circular connector with high-speed digital communication

bmsIncluded

0

capacityLoss

1 %

cellMonitoring

Cell voltages and temperatures, battery current

chemistry

Lithium Iron Phosphate (LiFePO4 or LFP)

colour

Blue (RAL 5012)

cycleDesignLife50

5,000 cycles

cycleDesignLife70

3,000 cycles

cycleDesignLife80

2,500 cycles

depth

160 mm

efficiency

92 %

eMC

EN-IEC 61000-6-2,EN-IEC 61000-6-3

endDischargeVoltage

11.2 V

energyLoss

1 %

firmwareUpdates

Battery firmware automatically updated by BMS

floatChargeVoltage

13.5 V

height

235 mm

internalResistance

2 m?

material

ABS

maxBatteryPerBms

50 (384kWh per BMS) (Up to 5 BMS-es can be paralleled)

maxContinuousChargeCurrent

100 A

maxContinuousDischargeCurrent

100 A

maxHumidity

95 %

maxPulseChargeCurrent

200 A

maxPulseDischargeCurrent

200 A

mountingMethod

Strap or mounting brackets

mountingOrientation

The lithium battery can be mounted upright and on its side, but not with the battery terminals facing down

nominalEnergy

1,280 Wh

performance

IEC 62620

protectionCategory

IP65

repairable

Yes (cover can be removed with screws)

requiresExternalBMS

1

safetyBattery

IEC 62619 (pending),UL 2054

safetyCells

IEC 62619,UL 1973,UL 9540A

selfDischargeRate

3 %

storageTempRange

weight

9 kg

width

197 mm
