EasySolar-II GX Victron Energy sku PMP242307010

Назва характеристики

Величина

aCConnectionTerminalType

aCInputFrequencyRange

[45, 65] Hz

aCInputVoltageRange

[187, 265] VAC

aCOutputFrequency

50 Hz

aCOutputVoltage

230 VAC

antiIslandingStandard

See our website

auxAcCurrent

32 A

AuxiliaryOutput

Так

batteryConnectionTerminalType

M8 bolts

batteryVoltageNominal

24 V

chargeAlgorithm

Adaptive, 4-stage

chargeVoltageAbsorption

28.8 VDC

chargeVoltageFloat

27.6 VDC

chargeVoltageStorage

26.4 VDC

colour

Blue (RAL 5012)

communicationPort

VE.Direct,VE.Bus,VE.Can,BMS-Can,WiFi,Ethernet

computerProgramming

Так

contPowerVA25

3,000 VA

contPowerW25

2,400 W

contPowerW40

2,200 W

contPowerW55

1,700 W

dCInputVoltageRange

[19, 33] VDC

depth

237 mm

emissionImmunity

EN 55014-1,EN 55014-2,EN-IEC 61000-3-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3

externalAcCurrentSensor

100A (optional)

fanAssistCooling

Так

height

499 mm

includesMPPT

Так

material

Aluminium

maxAcInputCurrent

32 A

maxAltitude

2,000 m

maxAppFeedinPower

3,000 VA

maxEfficiency

94 %

maxHumidity

95 %

maxiEfficiencySolarCharger

99 %

maximumBatteryChargeCurrent

70 A

maxOutputCurrentSolar

70 A

maxPvOpenCircuitVoltage

250 V

maxPvPower

2,000 W

operatingTempRange

peakPowerRating

5,500 W

powerAssist

Так

powerControl

Так

programmableRelay

AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC

protectionCategory

IP21

protections

Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple

pVConnectionTerminalType

M6 bolts

relayTerminal

Screw terminal 3-pole

remoteTerminal

On / Off

remoteTerminalType

Screw terminal two pole

safety

EN-IEC 60335-1,EN-IEC 60335-2-29,EN-IEC 62109-1,EN-IEC 62109-2

selfConsumption

20 mA

SolarChargerModel

MPPT 250/70-Tr

temperatureSensor

Included

transferSwitchCurrentRating

32 A

vebusTerminalType

Two RJ45 terminals

weight

26 kg

width

268 mm

zeroLoadPower

13 W

zeroLoadPowerAES

9 W

zeroLoadPowerSearch

3 W
