MultiPlus Victron Energy sku PMP245021010

Назва характеристики

Величина

aCConnectionTerminalType

M6 bolts

aCInputFrequencyRange

[45, 65] Hz

aCInputVoltageRange

[187, 265] VAC

aCInputVoltageRange1

[-0.8, 0.8] VAC

aCOutputFrequency

50 Hz

aCOutputVoltage

230 VAC

antiIslandingStandard

See our website

automotiveDirective

ECE R10-4

AuxiliaryOutput

Так

batteryConnectionTerminalType

M8 bolts (two for positive and two for negative connection)

batteryVoltageNominal

24 V

chargeAlgorithm

Adaptive, 4-stage

chargeVoltageAbsorption

28.8 VDC

chargeVoltageFloat

27.6 VDC

chargeVoltageStorage

26.4 VDC

colour

Blue (RAL 5012)

communicationPort

VE.Bus

communicationPortGeneral

Так

computerProgramming

Так

contPowerVA25

5,000 VA

contPowerW25

4,000 W

contPowerW40

3,700 W

contPowerW65

3,000 W

dCInputCurrent

125 V

dCInputVoltageRange

[18, 33] VDC

depth

240 mm

dIPSwitchesProgramming

Так

emissionImmunity

EN 55014-1,EN 55014-2,EN-IEC 61000-3-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3

externalAcCurrentSensor

fanAssistCooling

Так

frequencySelect

50Hz or 60Hz

height

444 mm

material

Aluminium

maxAltitude

2,000 m

maxEfficiency

94 %

maxHumidity

95 %

maximumBatteryChargeCurrent

120 A

MaxOutputAcCurrent

19 A

MaxOutputAcCurrentFault

53 A

numberAcInputs

1

numberAcOutputs

2

operatingTempRange

ovciiiIcw

6kA 30mS

parallelOperation

Так

peakPowerRating

10,000 W

pollutionDegree

2

powerAssist

Так

powerControl

Так

powerFactor

1

programmableRelay

AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC

protectionCategory

IP20

protections

Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple

relayTerminal

Screw terminal 3-pole

remoteTerminal

On / Off / Charger only

remoteTerminalType

Screw terminal two pole

safety

EN-IEC 60335-1,EN-IEC 60335-2-29,EN-IEC 62109-1

starterBatteryChargeCurrent

4 A

starterBatteryChargeOutput

Так

temperatureSensor

Included

threePhaseOperation

Так

transferSwitchCurrentRating

100 A

upsStandard

vebusTerminalType

Two RJ45 terminals

weight

30 kg

width

328 mm

zeroLoadPower

30 W

zeroLoadPowerAES

25 W

zeroLoadPowerSearch

10 W
