SmartSolar MPPT 150/70 up to 250/100 VE.Can Victron Energy sku SCC115070511

Назва характеристики

Величина

batteryConnectionTerminalType

batteryVoltageAutoSelect

12V / 24V / 48V Auto Select (software tool needed to select 36V)

bluetooth

Так

chargeAlgorithm

Multi-stage adaptive (adjustable)

colour

Blue (RAL 5012)

dataCommunication

Bluetooth,VE.Direct,VE.Can

dataRetentionPeriod

46 d

dataStored

Battery voltage,Battery current,Battery temperature,PV voltage,PV current,Load output Current

depth

95 mm

environmentalCondition

Indoor, unconditioned

height

215 mm

loadConnectionTerminalType

material

maxAltitude

5,000

maxEfficiency

98 %

maxHumidity

95 %

maxPVCurrentPerMc4

30 A

maxPVOpenCircuitVoltage

150 V

maxPVShortCircuitCurrent

50 A

nominalPVpower12V

1,000 W

nominalPVpower24V

2,000 W

nominalPVpower36V

3,000 W

nominalPVpower48V

4,000 W

numberOfSyncParallelOperatingUnits

25

numberOfSyncParallelOperatingUnitsBT

10

numberOfTrackers

1

operatingTempRange

pollutionDegree

PD3

programmableRelay

DPST AC rating: 240VAC / 4A, DC rating: 4A up to 35VDC, 1A up to 60VDC

protectionCategory

IP22 (connection area),IP43 (electronic components)

protections

Excessive temperature,Output short-circuit,PV reverse polarity

pVConnectionTerminalType

MC4 connectors (two pairs)

ratedChargeCurrent

70 A

relayTerminalConnection1

Screw terminal 3-pole

remoteOnOffTerminal

Так

remoteOnOffTerminalConnection

Screw terminal two pole

safety

CSA C22.2,EN-IEC 62109-1,UL 1741

selfConsumption

Less than 35mA @ 12V / 20mA @ 48V

startUpPVDCVoltage

The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V

temperatureCompensation12V

temperatureCompensation24V

temperatureCompensation48V

temperatureSensor

Internal

weight

3 kg

width

250 mm
