Quattro Victron Energy sku QUA483100102

Назва характеристики

Величина

aCConnectionTerminalType

M6 bolts

aCInputFrequencyRange

[55, 65] Hz

aCInputVoltageRange2

[90, 140] V

aCOutputFrequency

60 Hz

aCOutputVoltage

120 VAC

antiIslandingStandard

See our website

AuxiliaryOutput

Так

batteryConnectionTerminalType

M8 bolts (two for positive and two for negative connection)

batteryVoltageNominal

48 V

chargeAlgorithm

Adaptive, 4-stage

chargeVoltageAbsorption

57.6 VDC

chargeVoltageFloat

55.2 VDC

chargeVoltageStorage

52.8 VDC

colour

Blue (RAL 5012)

communicationPort

VE.Bus

communicationPortGeneral

Так

contPowerVA25

10,000 VA

contPowerW25

8,000 W

contPowerW40

6,500 W

contPowerW65

4,500 W

dCInputVoltageRange

[38, 66] VDC

depth

344 mm

emissionImmunity

EN 55014-1,EN 55014-2,EN-IEC 61000-3-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3

fanAssistCooling

Так

frequencySelect

height

572 mm

integratedTransferSwitch

Так

material

Aluminium

maxEfficiency

96 %

maxFeedTroughCurrent

2x 100A

maxHumidity

95 %

maximumBatteryChargeCurrent

140 A

numberAcInputs

2

operatingTempRange

parallelOperation

Так

peakPowerRating

20,000 W

powerAssist

Так

powerControl

Так

programmableRelay

AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC

protectionCategory

IP21

protections

Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple

relayTerminal

Screw terminal 3-pole

remoteTerminal

On / Off / Charger only

remoteTerminalType

Screw terminal two pole

safety

EN-IEC 60335-1,EN-IEC 60335-2-29,EN-IEC 62109-1,UL 1741

temperatureSensor

Included

threePhaseOperation

Так

vebusTerminalType

Two RJ45 terminals

weight

58 kg

width

488 mm

zeroLoadPower

60 W

zeroLoadPowerAES

40 W

zeroLoadPowerSearch

15 W
