BlueSolar PWM Victron Energy sku SCC040030020
Characteristics:
Code: SCC040030020
Manufacturer: Victron Energy
Reviews: 0 Leave a review
Product quality: Original goods
Product condition: New
Category: Solar charge controllers
Delivery terms
GROZBER Logistics or Third Party Delivery Services
Every day 24/7, orders are sent before 19:30 on weekdays, on Saturday - until 17:00. The shipping price varies depending on the weight, the set price of the delivered product and the rates of the delivery service.
Pickup from GROZBER warehouses
Scheduled transport
Every day 24/7, orders are sent before 19:30 on weekdays, on Saturday - until 17:00. The shipping price varies depending on the weight, the set price of the delivered product and the rates of the delivery service.
Pickup from GROZBER warehouses
- • Warehouse store in Kyiv, Academician Glushkov Ave, 1
- • Warehouse store in Bila Tserkva, st. Ivan Kozhedub, 359
- • Warehouse store in Nizhyn, st. Cosmonauts, 25
Scheduled transport
Payment
- • C.O.D
- • Cashless payment with VAT to the company's bank account
- • Cashless payment on a bank card of an individual
- • Cash in our office
Return / exchange conditions
Return of goods is carried out in accordance with the legislation of Ukraine.
| Batch number | Name | Manufacturer | Price | Amount | Availability | Buy |
|---|---|---|---|---|---|---|
|
Position you are looking for
|
||||||
| The consignment #1 |
BlueSolar PWM
|
Victron Energy | ||||
Description:
BlueSolar PWM-Pro
The BlueSolar PWM-Pro series is ready for use with its default settings. It also is fully programmable.
• Lighting control function, fully programmable.
• Three stage battery charging (bulk, absorption, float), fully programmable.
• Integrated battery monitor function (Remote Panel needed to display state of charge).
• Load output with low voltage disconnect and manual control (default setting).
• Optional external temperature sensor.
• Load output protected against over load and short circuit.
• Protected against reverse polarity connection of the solar panels and/or battery.
• Day/night timing options: see manual Remote Panel for details.
BlueSolar PWM-Light
• Load output with low battery voltage disconnect function.
• Lighting control function, one timer only.
• Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.
• Three stage battery charging (bulk, absorption, float), not programmable.
• Load output protected against over load and short circuit.
• Protected against reverse polarity connection of the solar array and/or battery.
• Day/night timing options: see manual for details
Назва характеристики | Величина |
automaticLoadDisconnect | Так |
batteryConnectionTerminalType | |
batteryVoltage | 48V |
chargeVoltageAbsorption | 56.8V |
chargeVoltageBulk | 58.0V |
chargeVoltageFloat | 55.2V |
colour | Blue (RAL 5012) |
depth | 33.5 mm |
emission | EN-IEC 61000-6-1,ISO 7637-2,EN-IEC 61000-6-3 |
grounding | Common positive |
height | 95 mm |
loadConnectionTerminalType | |
loadOutput | Manual control + low voltage disconnect |
lowVoltageLoadDisconnect | 44.8V |
lowVoltageLoadReconnect | 50.4V (manual) 52.4V (automatic) |
material | |
maxHumidity | 95 % |
maxSolarVoltage | 100V |
operatingTempRange | |
OverloadProtection130 | Shutdown after 60 seconds |
OverloadProtection160 | Shutdown after 5 seconds |
OverloadProtectionSC | Immediate shutdown |
protectionCategory | IP20 |
protections | Battery reverse polarity (fuse),Output short-circuit,Excessive temperature |
pvArray48v | Two solar panles with 72 cells in series,Four solar panles with 36 cells in series |
pVConnectionTerminalType | |
ratedChargeCurrent | 30 A |
remoteOnOffTerminalConnection | |
remotePanel | No |
safety | EN-IEC 62109-1 |
secondBatteryOutput | |
selfConsumption | 10 mA |
temperatureCompensation | No |
temperatureSensor | No |
weight | 0.17 kg |
width | 140 mm |
